Charmilles carbon bush and current supply Various types.

100446687 135008369 135015281 135014443 ​

Material: Carbin, copper, brass.

Application: Charmilles wire EDM machines

​

Charmilles Carbon Bush and Current Supply

Charmilles (GF Machining Solutions) EDM machines use carbon/graphite brushes (bushes) to transfer electrical current to rotating parts. Correct brush type, installation, and a stable current supply are vital for spark stability and machine performance.

Function and Types
Purpose: sliding electrical contact for spindles, rotary indexers, collectors, motors.
Materials: carbon/graphite, metal-graphite (e.g., copper-graphite) for higher conductivity.
Use OEM parts when possible for proper fit, spring pressure, and material grade.

Why Current Supply Matters
Stable, low-noise DC prevents voltage drops, arcing, and erratic discharges.
Poor contact or noisy supply causes surface defects, dimensional errors, overheating, and increased wear.

Symptoms of Problems
Visible arcing, sparking, smoke, or overheating at brushes.
Intermittent motor/rotary function, vibration.
Unstable sparks, poor surface finish, increased electrode wear.
Servo/spindle alarms or abnormal electrical readings.

Maintenance and Troubleshooting
Inspect brushes regularly for wear, glazing, cracks, contamination.
Check spring tension, holder alignment, and grounding.
Clean slip rings/commutators per manual; replace brushes as matched sets.
Measure DC voltage and ripple; use an oscilloscope for noise.
Swap holders or replace brushes if faults persist.

Installation Tips
Follow Charmilles manual for part numbers, sizes, torque, and break-in procedures.
Ensure clean contact surfaces and correct orientation; don’t mix old and new brushes.

Sourcing
Provide machine model/serial to suppliers. If using aftermarket parts, verify material grade, dimensions, and spring force.

Proper brushes and a stable current supply ensure reliable EDM performance, better surface finish, and longer component life.

Regular inspections and prompt replacement prevent machining issues，
